NPort 5000 Series User Manual
33
Web Interface for the NPort IA5000A Series
You must assign a valid IP address to the NPort before it will work in your network environment. Your
network system administrator should provide you with an IP address and related settings for your network.
The IP address must be unique within the network (otherwise, the NPort will not have a valid connection to
the network). You can choose from four possible IP configuration modes—Static, DHCP, DHCP/BOOTP,
and BOOTP—located under the web console screen’s IP configuration dropdown box.
Method
Function Definition
Static
The user must define the IP address, Netmask, and Gateway.
DHCP
The DHCP Server assigns the IP address, Netmask, Gateway, DNS, and Time Server
DHCP/BOOTP
The DHCP Server assigns the IP address, Netmask, Gateway, DNS, and Time Server, or
the BOOTP Server assigns the IP address (if the DHCP Server does not respond).
BOOTP
The BOOTP Server assigns the IP address.

Moxa Technologies NPort 5250A Specifications

General

Certification	CE, FCC EN 55022 Class A, FCC Part 15 Subpart B Class A EN 55024 EN 61000-4-4 EN 61000-4-5
Serial interface type	RS-232/422/485
Serial ports quantity	1
Supported network protocols	ICMP, IPv4, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, IGMP V1/2
Storage temperature (T-T)	-40 - 75 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Safety	UL 60950-1, EN 60950-1

Weight and Dimensions

Weight	340 g
Dimensions (WxDxH)	77 x 111 x 26 mm
