Moxa Technologies NPort 6650-32 User Manual

NPort 6000 Series Log, Monitoring and Warning
11-3
OpMode
Connect Op Mode is in use
Disconnect Op Mode switched from in use to disconnect.
Authentication Fail
The Authentication failed in terminal; reverse terminal; or dial in/out operation
modes
Restart
Serial port was restarted.
Configure the Remote Log Server
SYSLOG server
IP address or domain name of remote log server.
SYSLOG facility
Syslog Facility is one information field associated with a syslog message.
SYSLOG severity
Order of severity, listed from most severe to least severe.
0 Emergency
1 Alert
2 Critical
3 Error
4 Warning
5 Notice
6 Informational
7 Debug
System Monitoring
Users are able to view Serial Status and System Status under System Monitoring section. All monitor
functions will refresh automatically every five seconds unless the Auto Refresh box is unchecked.
Serial Status
Serial to Network Connections
Go to Serial to Network Connections under Serial Status to view the operation mode and status of each
connection for each serial port.

Moxa Technologies NPort 6650-32 Specifications

General

Display	LCD
Isolation	1.5 kV
Certification	CE, FCC, UL, CUL, TUV
Serial interface type	RS-232/422/485
Serial ports quantity	32
Ethernet LAN data rates	10, 100 Mbit/s
Surge protection voltage	0.5 kV
Security algorithms	3DES, 802.1x RADIUS, DES, HTTPS, SSH, SSL/TLS
Supported network protocols	ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, HTTP, SMTP, ARP, PPPoE, DDNS
Connectivity LEDs	Yes
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Input voltage	100 - 240 V
Safety	UL (UL60950-1), TÜV (EN60950-1)
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Weight	3580 g
