NPort 6000 Series Introduction
1-10
Standards and Certifications
Safety:
UL 60950-1
EMC:
55022/24
EMI:
CISPR 22, FCC Part 15B Class A
EMS:
IEC 61000
-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000
-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000
-4-4 EFT: Power 1 kV; Signal 0.5 kV
IEC 61000
-4-5 Surge: Power 1 kV; Signal: 1 kV
IEC 61000
-4-6 CS: 150 kHz to 80 MHz, 3 V/m; Signal: 3 V/m
IEC 61000
-4-8 PFMF IEC 61000-4-11 DIPs
Freefall:
IEC-68-2-6, IEC-68-2-34, IEC-68-2-32
Vibration:
IEC-68-2-6, IEC-68-2-34
Green Product:
RoHS, CRoHS, WEEE
Reliability
Alert Tools:
Built-in buzzer and RTC (real-time clock)
Automatic Reboot Trigger: Built-in WDT (watchdog timer)
MTBF
(mean time between failures)
Time:
850,905 hrs
Standard:
Telcordia (Bellcore) Standard TR/SR
Warranty
Warranty Period:
5 years
Details: See www.moxa.com/warranty
NPort 6610/6650
Ethernet Interface
Number of Ports:
1
Speed: 10/100 Mbps, auto MDI/MDIX
Connector:
8-pin RJ45
Magnetic Isolation:
1.5 kV built-in
Optical Fiber Interface (with network module)
100BaseFX
Multimode Single-mode
Wavelength 1300 nm 1310 nm
Max. TX -10 dBm 0 dBm
Min. TX -20 dBm -5 dBm
RX Sensitivity -34 to -30 dBm -36 to -32 dBm
Link Budget 12 dB 29 dB
Typical Distance 4 km
a
40 km
b
Saturation -6 dBm -3 dBm
a. 62.5/125 µm, 500 MHz*km fiber-optic cable
b. 9/125 µm, 3.5 PS/(nm*km) fiber-optic cable
Serial Interface
Number of Ports:
8, 16, or 32
Serial Standards:
NPort 6610:
RS-232
NPort 6650: RS
-232/422/485
Connector:
8-pin RJ45
RS
-485 Data Direction Control: ADDC® (Automatic Data Direction Control)
Console Port:
Dedicated RS-232 console port on rear panel (8-pin RJ45)
Serial Communication Parameters
Data Bits:
5, 6, 7, 8

Moxa Technologies NPort 6650-32 Specifications

General

Display	LCD
Isolation	1.5 kV
Certification	CE, FCC, UL, CUL, TUV
Serial interface type	RS-232/422/485
Serial ports quantity	32
Ethernet LAN data rates	10, 100 Mbit/s
Surge protection voltage	0.5 kV
Security algorithms	3DES, 802.1x RADIUS, DES, HTTPS, SSH, SSL/TLS
Supported network protocols	ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, HTTP, SMTP, ARP, PPPoE, DDNS
Connectivity LEDs	Yes
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Input voltage	100 - 240 V
Safety	UL (UL60950-1), TÜV (EN60950-1)
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Weight	3580 g
