19BA3431002/04 RU-EN
2 Commissioning
Number Description Figure
1 x Assembly kit
4x hex. nut
4x washer
4x spring washer
2 x Information label „Transport is
under surveillance“
2.2 Batteries and SIM card (only optional for IM100)
To replace the MLog batteries, unscrew the 10 Phillips-head screws on the rear of the MLog and remove the back.
The unit requires 6x LR14 alkaline batteries.
If you have an MLog IM100 with optional GSM module, you can now insert a SIM card into the SIM card holder.
NOTE
The SIM card must be inserted only with deactivated GSM
module and after prior entry of the PIN.
6x LR14
alkaline
batteries
(Varta 4014)
SIM card holder
Backup battery
for internal clock
NOTE
Use only standard alkaline batteries of the LR14
type.
Do not recharge alkaline batteries!
NOTE
Please dispose of used batteries in a proper
manner!
Remove the batteries if the device is not going
to be used for a prolonged period. There is a risk
that the batteries will leak as soon as they are
depleted.
Observe the note on the following page!
