3 Product description
17BA5831400-00 EN
cated in the thermometer pocket mounted in the transformer tank. The mea-
sured value is displayed directly on the pointer thermometer or, as an option,
on an analog or digital display using a signal converter.
Figure1: Example of temperature measurement and temperature display
1 Transformer 2 Pointer thermometer for winding
temperature
3 Digital signal converter 4 Transformer fan
5 SCADA 6 Digital display/analog display
7 Analog signal converter 8 Pointer thermometer for oil temper-
ature
