3 Product description

22 BA5831400-00 EN

3.3.5 Temperature sensor

Figure6: Temperature sensor

1 Step protection (optional) * 2 Small screw connection on tem-

perature sensor

3 Large screw connection on tem-

perature sensor *

4 Temperature sensor

5 Capillary line

*) only for No.6 VA and No.7 sensors [►Section 10.3, Page 85]

3.4 Versions

The MESSKO Compact pointer thermometer is available in the following ver-

sions:

MESSKO Compact Standard MT-ST160SK and

MESSKO Compact RM MT-ST160RM

▪ Display of the oil temperature.

▪ Pointer thermometer with adjustable micro-switches.

▪ The displayed temperature corresponds to the oil temperature at the tem-

perature sensor of the pointer thermometer.

▪ The mechanical measurement system functions independently and with-

out a power source.
