5 Installation and commissioning
44 BA5831400-00 EN
5.4.2 Removing the bayonet seal ring
Before connecting, setting or testing the pointer thermometer, the bayonet
seal ring must be removed.
► Turn the bayonet seal ring counter-clockwise to the stop.
Figure22: Removing the bayonet seal ring
► Lift off the bayonet seal ring along with the viewing glass and rubber gas-
ket and place them safely on a clean, even storage surface.
