10 Appendix
88 BA5831400-00 EN
10.6 Cable gland dimensions
Standard cable screw connection
M25x1.5 nickel-plated brass
Clamping range 9...20mm
Figure70: Standard cable screw connection
1 Screw connection base: wrench
size 30
2 Pressure ring
3 Universal sealing ring, NBR 4 Pressure ring
5 Dust protection disk 6 Pressure screw; wrench size 28
