5 Installation and commissioning
48 BA5831400-00 EN
5.4.4.2 WADI cable gland (stainless steel or brass)
1. NOTICE! If the cable gland is not used, equip it with a sealing plug or re-
place the entire cable gland with a dummy plug in order to ensure the IP
degree of protection.
2. Remove the locking screw on the adapter.
Figure28: Removing the locking screw
3. Unscrew the provided cable gland and remove the dust protection disk.
Figure29: Removing the dust protection disk
