5 Overview of parameters
24
Overview of parameters
This section contains an overview of the relevant menus
and parameters. The availability of individual parameters
varies depending on the device ordered.
Parameter Setting range Factory setting Current setting
NORMset
Normset activation On, Off Off
Desired value 1 49...140 V 100 V
Primary voltage 0...9,999 kV 0 kV
Secondary voltage 57...123 V 100 V
Control parameters > Voltage regulation
Desired value 1 49...140 V 100.0 V
Desired value 2 49...140 V 100.0 V
Desired value 3 49...140 V 100.0 %
Desired value selec-
tion
Desired value 1;
Desired value 2;
Desired value 3
Desired value 1
Bandwidth 0.5...9 % 2.00 %
Delay time T1 0...600 s 40 s
Control response T1 T1 linear, T1 inte-
gral
T1 linear
Activation T2 T2 on, T2 off T2 off
Delay time T2 1...10 s 10.0 s
5
