MR TAPCON 230 - Page 25

5 Overview of parameters
25
Parameter Setting range Factory setting Current setting
Control parameters > Limit values
Undervoltage U< [%] 60...100 % 90 %
Delay time U< 0...20 s 10.0 s
Undervolt. blocking U< On, Off On
U< below 30 V On, Off Off
Overvoltage U> [%] 100...140 % 110 %
Overvolt. blocking U> On, Off Off
Overcurrent I> [%] 50...210 % 110 %
Overcurr. blocking I>. On, Off On
Undercurrent I< [%] 0...210 % 0 %
Undercurr. blocking I< On, Off Off
Neg. active power
block.
On, Off Off
Control parameters > Compensation
Compensation method LDC; Z LDC
Line drop compensa-
tion Ur
-25...25 V 0.0 V
Line drop compensa-
tion Ux
-25...25 V 0.0 V
Z compensation 0...15 % 0.0 %
Z comp. limit value 0...15 % 0.0 %
Configuration > Transformer data
