5 Overview of parameters
29
Parameter Setting range Factory setting Current setting
LED2 GPI 2
LED3 yellow Off
LED3 green Off
LED4 yellow Off
LED4 red Off
Configuration > Tap position
1)
Tap pos. capture see operating in-
structions
Off
Analog Val. [%] Tap
pos. min
0...100 % 0.0 %
Analog Val. [%] Tap
pos. max.
0...100 % 100.0 %
Lowest tap position -40...40 0
Highest tap position -40...40 19
Lower tap position
blocking
-128...128 0
Upper tap position
blocking
-128...128 40
Tap position limits
blocking behavior
Off; Directional;
Non-directional
Off
Configuration > Setting desired voltage level remotely
1)
Setting desired volt-
age level remotely
Off; 0/4..20 mA;
potentiometer
series
Off
