DIMENSION
IN mm
EXCEPT AS
NOTED
DOCUMENT NO.
STAND.
CHANGE NO.
DFTR.
CHKD.
SHEET
DATE
INSTALLATION DRAWING
-
SED 6134421 001 01
1
101177360E
STEPHAN
20.11.2018
1:1
1091025
SCALE
NAME
/
STREMPEL20.11.2018
MATERIAL NUMBER
SERIAL NUMBER
20.11.2018 KLEYN
ON-LOAD TAP-CHANGER VACUTAP® VVS®
1
© MASCHINENFABRIK REINHAUSEN GMBH 2018
THE REPRODUCTION, DISTRIBUTION AND UTILIZATION OF THIS DOCUMENT AS WELL AS THE COMMUNICATION OF ITS CONTENTS TO OTHERS WITHOUT EXPRESS AUTHORIZATION IS
PROHIBITED. OFFENDERS WILL BE HELD LIABLE FOR THE PAYMENT OF DAMAGES. ALL RIGHTS RESERVED IN THE EVENT OF THE GRANT OF A PATENT, UTILITY MODEL OR DESIGN.
A1
15
45MAX.
12M
5
7
0
O
6
3
0
O
660O
TRANSFORMER COVER
7
,
5
°
1
5
°
1
5
°
2
4
x
(
=
3
6
0
v
)
MOUNTING FLANGE ON
TRANSFORMER COVER
!
WITHDRAWAL HEIGHT
1819 MM
1364 MM
V V S III D - 76 kV
V V S III Y - 76 kV
ON-LOAD TAP-CHANGER
WITHDRAWAL HEIGHT
THE WITHDRAWAL HEIGHT CORRESPONDS TO THE CLEARANCE BETWEEN THE COVER FLANGE AND THE LIFTING
DEVICE OF THE OLTC INSERT, WHILE THE MOUNTING ROD IS INSERTED. ADDITIONAL FIXING PADS, WHICH MAY
BE NECESSARY FOR AFFIXING THE OLTC INSERT, HAVE TO BE CONSIDERED TOO.
V V S III Y - 40 kV
V V S III D - 40 kV
