MSA 9010 LCD - Page 21

MSA AUER
MSA
Configuration
Control Unit Models 9010 LCD and 9020 LCD
21
GB
CONFIGURATION 9010/20 LCD FOR SENSORS/TRANSMITTERS FOR GENERAL
PURPOSE BOARD [continued]
Connection type
FOUR-WIRE
SENSOR
FOUR-WIRE
SENSOR
SENSOR
THREE-WIRE
Type of
transmitter
Catalytic
Thermoconduct.
Oxygen cell
Thermoc. Cell
For analysers
Semiconductor D-8201
Sensor/trasm.
power supply
CURRENT VOLTAGE CURRENT
Input signal mV mV mV
Points to short
circuit
CH A CH B
CV1 CV1 pos. 1-2 pos. 2-3 pos. 1-2
CV2 CV2
CV3 CV3 
CV4 CV4
CV5 CV5 
CV6 CV6
CV7 CV7 *
CV8 CV8
CV9 CV9 pos. 1-2 pos. 1-2 pos. 2-3
CV10 CV10
CV11 CV11 *
CV12 CV12 
NOTES
 bridge closed
* depending on the
range and the gas
