Control Unit Models 9010 LCD and 9020 LCD
49
GB
Typical data of the transmitters Ultima XE,Ultima XIR,Ultima XI
XE [catalytic] XIR XI NOTES
Power supply 7-30 VDC 7-30 VDC 7-30 VDC
Number of con-
ductors
333
24VDC current
consumption - typ-
ical
150 mA 200 mA 200 mA
Output signal 4-20 mA 4-20 mA 4-20 mA Source type
Operating
temperature
-40 °C to +60 °C
Weight Approx. 5 kg 5 kg 3 kg
Dimensions 262x162x100 mm 150x320x100 mm Ø 64x203 mm
Material Stainless steel
Connection cable
data
Cable type Shielded at least 80%
Max line length
with 9010
Max line length
with 9020
900 m
[with relay]
700 m
500 m
[with relay]
250 m
500 m
350 m
With 1.5 mm² wire
Max load at
4-20 mA
600 Ohms 600 Ohms 600 Ohms At 24 VDC
The data refer to the nominal voltages and with a wire having a 1.5 mm² section
Distances must be derated by 25-30 % approx. if nominal voltages drop by 15-20 %
For other data or more details, consult the specific manual or contact the Technical Support
Department
