4 ProtoCessor Power Requirements
NOTE:Visit the MSA website ProtoCessor page for the latest information.
Power Requirement for ProtoCessor ASP at 3.3V through 5 VDC
Standalone ProtoCessor
ProtoCessor Type Mk 2 3.3VDC 5 VDC
FPC-AD2 (Typical) 100mA 120mA
FPC-AD2 (Maximum) 120mA 140mA
NOTE: These values are ‘nominal’ and a safety margin should be added to the power supply of the host system.
A safety margin of 25% is recommended.
Power Requirement for ProtoCessor FFP-Modules
Standalone ProtoCessor
ProtoCessor Type Mk 3 3.3VDC 5VDC
FPC-ED2 (Typical) 425mA 280mA
FPC-ED2 (Maximum) 530mA 350mA
FPC-ED4 (Typical) 582mA 355mA
FPC-ED4 (Maximum) 725mA 480mA
NOTE: These values are ‘nominal’ and a safety margin should be added to the power supply of the host system.
A safety margin of 25% is recommended.
ProtoCessor Design Guide 12
