8 Recommended Connectors, Cables and Mechanics
8.1 ProtoCessor Pin Headers
Recommend use of the following SAMTEC Pin Headers on host board:
Part Numbers TLW-1xx-x-S
Manufacturer SAMTEC
Link to Data Sheets www.samtec.com/ftppub/pdf/tsw_th.pdf
8.2 Expansion Connector for ASP – FPC-AD4 and FPC-AD5
Recommend use of the following connector on the host board:
Header Part Number FTS-110-01-F-DV
Manufacturer SAMTEC
Link to Data Sheet www.samtec.com/ftppub/pdf/fts.pdf
8.3 Expansion Cable for ASP – FPC-AD4 and FPC-AD5
NOTE:Expansion Cable for ASP - Available on request (cable only works in combination with right angle
expansion connector on ASP board).
Recommend use of the following cables on the expansion connector:
Cable Part Number FFSD-10-S-10.00-01-N (Single Ended Ribbon)
Cable Part Number FFSD-10-D-10.00-01-N (Double Ended Ribbon)
Manufacturer SAMTEC
Link to Data Sheet www.samtec.com/ftppub/pdf/ffsd.pdf
Recommend use of the following cables on the expansion connector:
Cable Part Number SFSD-10-28-H-10.00-S
Cable Part Number TFSD-10-28-H-10.00-D-NUS
Manufacturer SAMTEC
Link to Data Sheet www.samtec.com/ftppub/pdf/sfss.pdf www.samtec.com/ftppub/pdf/tfsd.pdf
8.4 Mechanics – Standoff
This Nylon post (standoff) will provide the required 0.312” spacing as per Section 9.2 Mechanical Drawings – ProtoCessor.
Part Number DLMSPM-4-01
Manufacturer Essentra Components
Link to Website www.essentracomponents.com
