9.3 Specifications
Field Connections
FPC-AD2: RS-485
FPC-E03: Ethernet
FPC-ED2: RS-485 & Ethernet
FPC-ED4: FTT-10 & Ethernet
Approvals BTL marked; LonMark certified (FPC-ED4), ODVAconformant
CAN ICES-003(A)/
NMB-003(A)
FPC-ED2, FPC-ED4
Power Requirements
FPC-AD2: 0.6W
FPC-E03: 1.4W
FPC-ED2: 1.75W
FPC-ED4: 2.4W
Physical Dimensions
FPC-AD2: 2.2 x 1.2 x 0.5 in. (5.6 x 3.0 x 1.3 cm)
FPC-E03: 1.8 x 1.2 x 0.8 in. (4.6 x 3.0 x 2.0 cm)
FPC-ED2: 2.7 x 1.2 x 0.8 in. (6.9 x 3.0 x 2.0 cm)
FPC-ED4: 3.3 x 1.2 x 0.8 in. (8.5 x 3.0 x 2.0 cm)
Weight 0.04 kg (0.1 lbs)
Operating Temperature -40°C to 85°C (-40°F to 185°F)
Surge Suppression EN61000-4-2 ESD EN61000-4-3 EMC EN61000-4-4 EFT
Humidity 5-90% RH (non-condensing)
Warning: This equipment is compliant with Class A of CISPR 32. In a residential environment, this equipment
may cause radio interference.
NOTE:Specifications subject to change without notice.
9.4 Warnings
FCC Class A (FPC-ED2, FPC-ED4)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
