MSA SMC 5100-IT Series User Manual

Input
Remote Alarm Reset Normally open digital input
Power
Power consumption 2 watts (4 watts for 5100-88-IT)
Input voltage 24 VDC nominal: 10-30 VDC
Operating Range
Ambient Temp (°F) Ambient Temp (°C) Relative Humidity
5100-03-IT O
2
-4 to 122 °F -20 to 50 °C 15 – 90%
5100-04-IT CO -4 to 122 °F -20 to 50 °C 15 – 90%
5100-05-IT H
2
S
(1)
- 40 to 140 °F -40 to 60 °C 15 – 90%
5100-06-IT Cl
2
-4 to 122 °F -20 to 50 °C 15 – 90%
5100-08-IT ClO
2
-4 to 122 °F -20 to 50 °C 15 – 90%
5100-10-IT SO
2
-4 to 122 °F -20 to 50 °C 15 – 90%
5100-12-IT NO
2
-4 to 122 °F -20 to 50 °C 15 – 90%
5100-25-IT NH
3
+14 to 113 °F
-10 to 45 °C
20 – 95%
5100-26-IT HF +14 to 113 °F -10 to 45 °C 20 – 95%
5100-88-IT CO
2
- 40 to 140 °F -40 to 60 °C 15 – 90%
(1) Performance tested by FM Approvals to -40°C/°F
Enclosure
Material - Aluminum Polyester powder-coated, sand-cast, copper-free aluminum
Material - Stainless Steel 316 Stainless Steel
Dimensions (HxWxD) (differs
for 5100-25-IT & 5100-26-IT)
(A1 & A2) 7.9 x 5.7 x 3.9 in. (20.1 x 14.5 x 9.9 cm)
(S1 & S2) 7.6 x 4.4 x 4.9 in. (19.3 x 11.2 x 12.4 cm)
Weight (A1 & A2) 3.4 lb. (1.5 Kg)
(S1 & S2) 7.2 lb. (3.3 Kg)
Electrical Approvals (5100-05-IT Only)
Factory Mutual (FM) Class 1, Div. I, Groups B, C, D
FM Standards 3600, 3615, 3810
ATEX (5100-XX-IT) II 2 G Ex d IIB+H2 T6 Gb Ta = -40°C to +50°C
SMC 5100-XX-IT Toxic Gas Detector Module 41
US 8 Specifications
