3-24
MS-6585 ATX Mainboard
PC Health Status
This section shows the status of your CPU, fan, overall system status,
etc. Monitor function is available only if there is hardware monitoring
mechanism onboard.
CPU/SYSTEM Temperature, CPU FAN Speed, Vcore, +3.3V, +5.0V, +12V,
-12V, -5.0V, Battery
These items display the current status of all of the monitored hardware devices/
components such as CPU voltages, temperatures and all fans’ speeds.
CPU Fan Beep
This allows you to use the function of warning beep when the CPU fan stops.
