MSI MEG X299 CREATION User Manual

29
Overview of Components
Component Contents
Port Name Port Type Page
BIOS_SW1 Multi-BIOS Switch 54
CPU_FAN1, PUMP_FAN1,
SYS_FAN1~4, EXS_FAN1~2
Fan Connectors 47
CPU_PWR1~3, ATX_PWR1,
PCIE_PWR1
Power Connectors 43
CPU Socket LGA2066 CPU Socket 30
JAUD1 Front Audio Connector 42
JBAT1 Clear CMOS (Reset BIOS) Jumper 52
JCI1 Chassis Intrusion Connector 53
JCORSAIR1 CORSAIR Connector 56
JFP1, JFP2 Front Panel Connectors 42
JPWRLED1 LED power input 58
JRGB1, JRAINBOW1~2 RGB LED connectors 55
JSLOW1 Slow Mode Booting Jumper 46
JTBT1 Thunderbolt Add-on Card Connector 48
JUSB1~2 USB 2.0 Connectors 51
JUSB3~4 USB 3.1 Gen1 Connectors 50
JUSB5 USB 3.1 Gen2 Type-C Connector 51
M2_1~3 M.2 Slots (Key M) 38
OC1 GAME BOOST Knob 44
OC_FS1 OC Force Enter BIOS Jumper 46
OC_RT1 OC Retry Jumper 46
PCI_E1~5 PCIe Expansion Slots 34
POWER1, RESET1 Power Button, Reset Button 52
SATA1~8 SATA 6Gb/s Connectors 41
T_SEN1 Thermal Sensor Connector 48
U2_1 U.2 Connector 37
VRAID1 Virtual RAID on CPU Connector 41
W_FLOW1 Water Flow Meter Connector 48

MSI MEG X299 CREATION Specifications

General

Memory channels	Quad-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	4100, 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3333, 3400, 3466, 3600, 3733, 3800, 4000, 4200 MHz
Processor socket	LGA 2066 (Socket R4)
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ X-series
Supported processor sockets	LGA 2066
USB 2.0 connectors	2
ATX Power connector (24-pin)	Yes
Number of SATA II connectors	0
Number of SATA III connectors	8
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	SATA III, U.2
BIOS type	UEFI AMI
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC1220
Component for	PC
Motherboard chipset	Intel® X299
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
Windows operating systems supported	Windows 10
LAN controller	Realtek RTL8125-CG, Intel I219-V
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
Ethernet interface type	2.5 Gigabit Ethernet, Gigabit Ethernet
Parallel processing technology support	CrossFire, SLI
Cables included	SATA

Weight and Dimensions

Depth	272 mm
Width	305 mm
