Indicateurs LED embarqués
Tableau des caractères hexadécimaux
Hexadécimaux 0 1 2 3 4 5 6 7 8 9 A B C D E F
Affichage de
Debug Code
LED
0 1 2 3 4 5 6 7 8 9 A B C D E F
Phase de démarrage
Sécurité (SEC)- initialisation de très bas niveau
Initialisation Pre-EFI (PEI) – initialisation de la mémoire
Environnement d’exécution des pilotes (DXE) – initialisation du matériel principal
Sélection du périphérique de démarrage (BDS) – la configuration du système,
l’interface d’utilisateur de pré-OS et la sélection d’un périphérique amorçable (CD /
DVD, disque dur, USB, réseau, interface système, etc.)
Tableau de Debug Code LED
Codes de progression SEC
01 Sous tension. Détection du type de réinitialisation (soft / hard)
02 Initialisation AP avant chargement du microcode
03 Initialisation de l’agent système avant chargement du microcode
04 Initialisation PCH avant chargement du microcode
06 Chargement du microcode
07 Initialisation AP après chargement du microcode
08 Initialisation de l’agent système après chargement du microcode
09 Initialisation PCH après chargement du microcode
0B Initialisation du cache
Codes d’erreur SEC
0C - 0D Réservé aux futurs codes d’erreur AMI SEC
0E Microcode introuvable
0F Microcode non chargé
Codes de progression PEI
10 Le cœur PEI est lancé.
11 L’initialisation de la pré-mémoire du processeur est lancée
12 - 14 Initialisation de la pré-mémoire du processeur (module processeur spécifique)
15 L’initialisation de la pré-mémoire de l’agent système est lancée
16 - 18 Initialisation de la pré-mémoire de l’agent système (module agent système spécifique)
19 L’initialisation de la pré-mémoire du PCH est lancée
1A - 1C Initialisation de la pré-mémoire du PCH (module PCH spécifique)
2B Initialisation de la mémoire. Lecture des données SPD
2C Initialisation de la mémoire. Détection de présence de la mémoire
2D Initialisation de la mémoire. Information sur la programmation de synchronisation de la mémoire
2E Initialisation de la mémoire.Configuration de la mémoire
