MSI MEG X570 UNIFY User Manual

4
Specifications
Specifications
CPU
Supports 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with
Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with
Radeon™ Graphics Desktop Processors for Socket AM4
Chipset AMD®
X570 Chipset
Memory
∙ 4x DDR4 memory slots, support up to 128GB*
▪ 3rd Gen AMD Ryzen™ Processors support DDR4 1866/
2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by
JEDEC, and 2667/ 2800 /2933 /3000 /3066 /3200 /3466
/3600/ 3733 /3866 /4000 /4133 /4266 /4400 /4533 /4600
Mhz by A-XMP OC MODE
▪ 2nd Gen AMD Ryzen™ Processors, 1st and 2nd Gen
AMD Ryzen™ with Radeon™ Vega Graphics Processors
support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/
3066/ 3200 Mhz by JEDEC, and 2667 /2800 / 2933 /3000
/3066 /3200 /3466 /3600 Mhz by A-XMP OC MODE
∙ Dual channel memory architecture
∙ Supports non-ECC UDIMM memory
∙ Supports ECC UDIMM memory (non-ECC mode)
∙ Supports un-buffered memory
* Please refer www.msi.com for more information on compatible memory.
Expansion Slots
∙ 2x PCIe 4.0/ 3.0 x16 slots (PCI_E1, PCI_E3)
▪ 3rd Gen AMD Ryzen™ support PCIe 4.0 x16/x0, x8/x8
modes
▪ 2nd Gen AMD Ryzen™ support PCIe 3.0 x16/x0, x8/x8
modes
▪ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen
AMD Ryzen™ with Radeon™ Graphics support PCIe 3.0
x8 mode*
∙ 1x PCIe 4.0/ 3.0 x16 slot (PCI_E5, supports x4 mode)
∙ 2x PCIe 4.0/ 3.0 x1 slots**
* PCI_E3 slot is only available for 2nd and 3rd Gen AMD Ryzen™ processors.
** The PCIe x1 slots can not be used simultaneously. PCI_E2 will be unavailable
when installing the PCIe card in PCI_E4 slot.
***The speeds may vary for different devices
Continued on next page

MSI MEG X570 UNIFY Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	4533, 1866, 2133, 2400, 2667, 2800, 2933, 3000, 3200, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4600 MHz
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Parallel processing technology support	3-Way SLI, Crossfire
TPM connector	Yes
USB 2.0 connectors	2
Number of SATA II connectors	0
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
LAN controller	Realtek RTL8125
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC1220
Cooling type	Active
Component for	PC
Motherboard chipset	AMD X570
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64
BIOS type	UEFI AMI
Harmonized System (HS) code	84733020
Weight	1000 g

Weight and Dimensions

Depth	244 mm
Width	305 mm
Height	268 mm
