19
Vue d’ensemble des composants
PCI_E1~5 : Slots d’extension PCIe
Important
Si vous installez une carte graphique lourde, il vous faut utiliser un outil comme
la barre de support MSI Gaming Series pour supporter son poids et pour éviter la
déformation du slot.
Si vous choisissez d’installer une seule carte d’extension PCIe x 16, nous vous
recommandons d’utiliser le slot PCI_E1 pour profiter de performances optimales.
Veillez à toujours mettre l’ordinateur hors tension et à débrancher le cordon
d’alimentation avant d’installer les cartes d’extension. Référez-vous à la
documentation des cartes pour vérifier si un composant ou un logiciel doit être
modifié.
Les slots PCIe x 1 ne peuvent pas être utilisés simultanément. Le slot PCI_E2 est
indisponible lorsqu’une carte PCIe est installée dans le slot PCI_E4.
Tableau de la bande passante du PCle
Referez-vous au tableau ci-dessous pour installer les périphériques PCIe.
Pour AMD Ryzen™ de 3ème génération
Slot Unique 2-Way 3-Way*
PCI_E1 (CPU) @4.0 x 16 @4.0 x 8 @4.0 x 8
PCI_E2 (PCH) 4.0 x 1 4.0 x1 4.0 x1
PCI_E3 (CPU) @4.0 x 8 @4.0 x 8
PCI_E4 (PCH) 4.0 x 1 4.0 x 1 4.0 x 1
PCI_E5 (PCH) 4.0 x 4 4.0 x 4 @4.0 x 4
(─ : indisponible, @ : carte graphique, * : CrossFire uniquement)
Slots
AMD Ryzen™ de
3ème génération
AMD Ryzen™ de
2ème génération
Ryzen™ avec cœurs
graphiques Radeon™
Vega et AMD Ryzen™
avec cœurs graphiques
Radeon™ de 2ème
génération
PCI_E1 PCIe 4.0 x 16 PCIe 3.0 x 16 PCIe 3.0 x 8
PCI_E2 PCIe 4.0 x 1 PCIe 3.0 x 1 PCIe 3.0 x 1
PCI_E3 PCIe 4.0 x 8 PCIe 3.0 x 8 Indisponible
PCI_E4 PCIe 4.0 x 1 PCIe 3.0 x 1 PCIe 3.0 x 1
PCI_E5 PCIe 4.0 x 4 PCIe 3.0 x 4 PCIe 3.0 x 4
