16
Continued from previous column
Thunderbolt 4
Intel® JHL8540 Thunderbolt™ 4 Controller
2x Thunderbolt™ 4 (USB-C) ports on the back panel
• Supports up to 40Gbps transfer rate with Thunderbolt
devices
• Supports up to 20Gbps transfer rate with USB4 devices
• Supports up to 10Gbps transfer rate with USB 3.2
devices
• Supports up to 5V/3A ,15W power charging
• Each port can daisy-chain up to three Thunderbolt 4
devices or five Thunderbolt 3 devices
• Supports up to 8K display (need to connect the
DisplayPort of the motherboard or discrete graphics
card to the Mini DisplayPort Input port on the back
panel)
SATA Ports
6x SATA 6Gb/s ports
• SATA 5~8* (From Z790 chipset)
• SATA A1~A2 (From ASM1061)
* SATA7 will be unavailable when installing M.2 SATA SSD in the M2_5 slot.
Continued on next column
