49
BIOS_SW1: Multi-BIOS Switch
This motherboard has two built-in BIOS ROMs. If one is crashed, you can shift to the
other for booting by sliding the switch.
Important
Do not use the Multi-BIOS switch when system is booting up.
You can also use the MSI Center or Flash BIOS Button to flash BIOS. Please refer to
BIOS section for details.
BIOS B
BIOS A
(Default)
T_SEN1~2: Thermal Sensor Connector
These connectors allow you to connect the thermistor cable and use it to monitor the
temperature of the detection point.
Thermistor cable
GND
Sense
