Wi-Fi & Bluetooth®
Intel® Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E)
slot
Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz*(160MHz)
up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth® 5.3**, FIPS, FISMA
* The usage of Wi-Fi 6GHz band relies on Windows 11 support and depends on
every country’s regulations.
** The Bluetooth version may be updated, please refer to the Wi-Fi chipset
vendor’s website for details.
Power Connectors
1x 24-pin ATX main power connector
2x 8-pin ATX 12V power connectors
1x 6-pin PD power connector*
* To achieve USB PD 60W charging for JUSB6, PD_PWR1 connector needs to be
connected to the power supply unit.
Internal USB
Connectors
2x USB 3.2 Gen 2x2 20Gbps Type-C front panel
connectors*/** (From Z790 chipset)
Supports USB PD 60W fast charging
2x USB 3.2 Gen 1 5Gbps connectors (From Hub GL3523)
Supports additional 4 USB 3.2 Gen 1 5Gbps ports
2x USB 2.0 Type-A connectors (From Hub GL850G)
Supports additional 4 USB 2.0 ports
* JUSB6 doesn’t support USB 2.0 device.
** To achieve 60W PD fast charging for JUSB6, the PD_PWR1 connector needs
to be connected to the power supply unit.
Fan Connectors
1x 4-pin CPU fan connector
2x 4-pin water-pump fan connectors
5x 4-pin system fan connectors
System Connectors
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x 3-pin Water Flow connector
1x TPM module connector
1x Tuning Controller connector
