MSI MEG Z790 ACE - Page 36

34
2. Slightly lift up the end part of Screwless M.2 Shield Frozr heatsink and move it
forward to uninstall the heatsink.
22
3. Remove the protective films from the M.2 thermal pads on the M.2 plate.
33
4. Remove or exchange the screws according to your SSD length. Skip this step, if you
install 2280 SSD.
44
44
22110 SSD
2260 SSD
