CHAPTER 2 HARDWARE INSTALLATION
123
2.3 External Battery Connector: JBAT
A battery must be used to retain the system board configuration in CMOS
RAM. If you use the on-board battery you must short pins 1,2 of JBAT to
keep the CMOS data.
