MSI MS-5148 - Chipset Features Setup; DRAM Timing and Burst Settings

CHAPTER 3 AWARD BIOS SETUP
Auto Configuration :Enabled
DRAM Timing :70ns
DRAM Leadoff Timing :10/6/4
DRAM Read Burst (EDO/FP) :x333/x444
DRAM Write Burst Timing :x333
Fast EDO Lead odd :Disabled
Refresh RAS# Assertion :3
Fast RAS to CAS Delay :3
DRAM Page IDLE Timer :2
DRAM Enhanced Paging :Enabled
Fast MA to RAS# Delay :2 Clks
SDRAM (CAS Lat/RAS-to-CAS):3/3
SDRAM Speculative Read :Disabled
System BIOS Cacheable :Disabled
Video BIOS Cacheable :Disabled
8 Bit I/O Recovery Time :1
16 Bit I/O Recovery Time :2
Memory Hole at 15M-16M :Disabled
PCI 2.1 compliance :Disabled
3.6 Chipset Features Setup
The Chipset Features Setup option is used to change the values of
the chipset registers. These registers control most of the system options in
the computer.
Choose the “CHIPSET FEATURES SETUP” from the Main Menu and
the following screen will appear.
ROM PCI/ISA BIOS(2A59IM4A)
CMOS SETUP UTILITY
CHIPSET FEATURES SETUP
Note: Change these settings only if you are familiar with the chipset.
Esc : Quit ↑ ↓ → ← : Select item
F1 : Help PU/PD/+/- : modify
F5 : Old Value(Shift) F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
3-15
