CHAPTER 3 AWARD BIOS SETUP
SPP/(EPP/SPP)/
ECP(ECP/EPP)
RxD , TxD Active
Hi-Hi/Hi-Lo/ The user can choose between the preceding
Lo-Hi/Lo-Lo RxD (Receive Data), TxD (Transmit Data)
activity levels.
Onboard Parallel Port
Disabled/ There is a built-in parallel port on the on-board
Super I/O chipset that provides Standard, ECP,
and EPP features. It has the following options:
Disable
3BCH/IRQ7 Line Printer port 0
278H/IRQ5 Line Printer port 2
378H/IRQ5 Line Printer port 1
Onboard Parallel Mode
SPP : Standard Parallel Port
EPP : Enhanced Parallel Port
ECP : Extended Capability Port
To operate the onboard parallel port as Standard
Parallel Port only choose “SPP.” To operate the
onboard parallel port in the ECP and SPP modes
simultaneously choose “ECP/SPP.” By choos
ing “ECP” the onboard parallel port will operate
in ECPmode only. Choosing “ECP/EPP” will
allow the onboard parallel port to support both
the ECP and EPP modes simultaneously. The
ECP mode has to use the DMA channel so
choose the onboard parallel port with the ECP
feature. After selecting it the following message
(3BCH/IRQ7)/
(278H/IRQ5)/
(378H/IRQ5)
3-35
