CHAPTER 3 AWARD BIOS SETUP
3.10 Integrated Peripherals
ROM PCI/ISA BIOS (2A69HM4D)
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
IDE HDD Block Mode
Enabled/Disabled Enabled allows the Block mode access for the
IDE HDD.
IDE Primary Master PIO
Auto/Mode0/Mode1-4
IDE Primary Slave PIO
Auto/Mode0/Mode1-4
IDE HDD Block Mode :Enabled
IDE Primary Master PIO :Auto
IDE Primary Slave PIO :Auto
IDE Secondary Master PIO :Auto
IDE Secondary Slave PIO :Auto
IDE Primary Master UDMA :Auto
IDE Primary Slave UDMA :Auto
IDE Secondary Master UDMA:Auto
IDE Secondary Slave UDMA :Auto
On-Chip Primary PCI IDE :Enabled
On-Chip Primary PCI IDE :Enabled
USB Keyboard Controller :Disabled
Onboard FDD controller :Enabled
Onboard Serial Port 1 :3F8/IRQ4
Onboard Serial Port 2 :2F8/IRQ3
UART 2 Mode :ASKIR
IR Function Duplex :Half
RxD , TxD Active :Hi , Hi
Onboard Parallel Port :378H/IRQ7
Esc : Quit ↑ ↓ → ← : Select item
F1 : Help PU/PD/+/- : modify
F5 : Old Value(Shift) F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
Onboard Parallel Mode :ECP/EPP
ECP Mode Use DMA :3
Parallel Port EPP Type :EPP1
3-31
