CHAPTER 2 HARDWARE INSTALLATION
2.9 Floppy Disk Connector: FDD
The system board also provides a standard floppy disk connector FDD that
supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. You can
attach a floppy disk cable directly to this connector.
