MS-7520 Mainboard
1-2
Mainboard Specifications
Processor Support
- Intel
®
i7 processors in the LGA1366 package
(For the latest information about CPU, please visit
http://global.msi.com.tw/index.php?func=cpuform2)
Supported QPI
- Up to 6.4 GT/s
Chipset
- IOH: Intel
®
X58 chipset
- ICH: Intel
®
ICH10R chipset
Memory Support
- 6 DDR3 DIMMs support DDR3 1333/ 1066/ 800 DRAM speed
(Memory size 24GB Max)
- Supports 1Gb/ 2Gb/ 4Gb DRAM size
- Supports x8/ x16 data lines per DIMM
- Supports up to 3 channels mode
(For more information on compatible components, please visit
http://global.msi.com.tw/index.php?func=testreport)
LAN
- Supports 2 PCIE LAN 10/100/1000 Fast Ethernet by Realtek 8111C
Audio
- X-Fi Xtreme Audio Card
- 24-bit/ 96 KHz audio quality
- 100dB SNR clarity
- Up to 7.1 ch EAX 5.0 Surround Sound
IDE
- 1 IDE port by JMicron JMB363
- Supports Ultra DMA 66/100/133 mode
- Supports PIO, Bus Master operation mode
SATA
- 6 SATA ports (SATA1~6) by ICH10R
- 4 SATA ports (SATA7~10 for storage devices only) by JMicron JMB322
- 2 E-SATA ports by JMicron JMB362
- Supports storage and data transfers at up to 3 Gb/s
RAID
- SATA1~6 support Intel Matrix Storage Technology (AHCI/ RAID 0/1/
5/10) by ICH10R
- Two E-SATA ports on back panel support RAID 0/ 1 & JBOD mode
by JMicron JMB362
