MSI MS-7520 ECLIPSE Series User Manual

1-3
Getting Started
Hardware RAID
- SATA7 & SATA8 support RAID 0/ 1 & JBOD mode by 1st JMicron
JMB322
- SATA9 & SATA10 support RAID 0/ 1 & JBOD mode by 2nd JMicron
JMB322
1394
- Supports 2 1394 ports (rear*1, front*1) by VIA VT6308P
Connectors
Back panel
- 1 PS/2 mouse port
- 1 PS/2 keyboard port
- 1 1394 port
- 2 eSATA ports
- 8 USB 2.0 Ports
- 2 LAN jacks
- 1 Clear CMOS button
On-Board Pinheaders / Connectors
- 2 USB 2.0 connectors
- 1 1394 connector
- 1 chassis intrusion pinheader
- 1 serial port pinheader
- 1 TPM Module pinheader
- 1 D-LED2 panel pinheader
TPM
- Supports TPM
Slots
- 3 PCI Express gen2 x16 slots, two Black PCIE x16 slots (PCI_E2 &
PCI_E4) support up to PCIE x16 speed, one Blue PCIE x16 slot
(PCI_ E5) supports up to PCIE x4 speed)
- 2 Black PCI Express x1 slots
- 2 PCI slot, support 3.3V/ 5V PCI bus Interface
Form Factor
- ATX (30.5cm X 24.5cm)
Mounting
- 9 mounting holes
