MS-7520 Mainboard
E-2
Introduction
DRIVER BOOSTER MANAGER offers RAID level 0 (Striping), RAID level 1 (Mirroring
and Duplexing)and JBOD (Concatenate) for SATA ports (SATA7/8 & SATA9/10) on
this mainboard.
RAID 0 breaks the data into blocks which are written to separate hard drives. Spreading
the hard drive I/O load across independent channels greatly improves I/O performance.
RAID 1 provides data redundancy by mirroring data between the hard drives and
provides enhanced read performance.
JBOD provides a method for combining drives of different sizes into one large disk.
Important
1.The least number of hard drives for RAID 0, RAID 1 or JBOD mode is 2. All
the information/ volumes/ pictures listed in your system might differ from
the illustrations in this appendix.
2.SATA7 & SATA8 support RAID 0/ RAID 1/ JBOD by 1st JMB322 (controller
1). And SATA9 & SATA10 support RAID 0/ RAID 1/ JBOD by 2nd JMB322
(controller 2).
