En-17
Englsh
Quad-Channel mode
Installed DIMMs
(4 memory modules)
Dagram
DIMM1, DIMM3,
DIMM5, DIMM7
DIMM1
DIMM2
DIMM3
DIMM4
DIMM8
DIMM7
DIMM6
DIMM5
Installed DIMMs
(8 memory modules)
Dagram
DIMM1, DIMM2,
DIMM3, DIMM4,
DIMM5, DIMM6,
DIMM7, DIMM8
DIMM1
DIMM2
DIMM3
DIMM4
DIMM8
DIMM7
DIMM6
DIMM5
Important
To ensure system stablty for mult-channel mode (Dual/ Trple/ Quad channel
mode), memory modules must be of the same type, number and densty. And for
every channel, the BLACK DIMM slot must to be nstalled FIRST.
Always nsert memory modules n the DIMM1 slot 󰘰rst.
•
•
