7.1 Open the air valve (a) on the bladder. Insert the
inflation hose (b) into the valve.
7.2 Press the Bubble button to inflate until it is
firm to touch but not hard.
7.3 Press Bubble button for more than 3
seconds to turn off the function. Disconnect the inflation
hose from the air blower outlet and the valve.
7.4 Replace the air valve cap (c) back on the control panel.
Close and recess the inflation valve (a).
6.6 When inflation is completed. Press Bubble button for more than 3 seconds to turn off the
function. Disconnect the inflation hose on both ends. Replace the air valve cap back.
NOTE:
The cap is designed to be screwed on and off. Never exert force as this could cause the compete
internal inflation system of the valve to come loose.
If over inflated, remove the inflation hose from the spa air valve side, screw the valve cap to
release some air and stop until the manometer points to the right color section.
13
11
6.1
6.2
6.3
(a)
(b)
(b)
(c)
6.4 Press the Bubble button to inflate the spa tub until it is firm to tough.
CAUTION: Do not over inflate. Over inflation may cause spa leakage and void the warranty.
6.5 Pay attention to the Manometer. The Yellow section appears when the spa is properly inflated. The
Green section shows when water filling is completed. Repeat previous steps if more air is necessary.
CAUTION: The Red section shows when the spa is over inflated. Press the black button (a) on the
manometer to release some air until it points the green section.
IMPORTANT: During spa use, the manometer shall only shows the Green section at all times.
6.4 6.5
Green
Yellow
Over Inflation
Red
Button
(a)
7.
7
(a)
(b)
(c)
Spa Bladder Inflation
