MST Impact NS5001 User Guide

Chapter
3
Installation
This chapter describes mounting options, installation schemes, and
antenna and cable connections. Fibre connector assembly and cable
termination are beyond the scope of this manual.
Topics:
•
NS50 Mounting Options
•
Antenna Mounting Options
Important: The electronic components in each NS50 have been
designed to be isolated from the enclosure and local electrical
•
Installation Schemes
•
Connecting power to the NS50
earth. This ensures there is no current passing between grounds
•
Handling Composite Cable
During Installation
of different potentials (known as galvanic isolation). Galvanic
isolation must always be maintained, with the NS50 ground
•
Connecting Composite Cable to
the NS50
terminals isolated from electrical earth, and all antenna and
antenna cable connections properly insulated.
•
Standard Composite and Fibre
Cable Lengths
•
Connecting Ethernet Cable to
the NS50
•
Connecting F-LINK Terminated
Composite Cable to the NS50
•
Connecting Antennas to the
NS50
•
Manual Reset and Reboot
NS50 User Guide25Revision C

MST Impact NS5001 Specifications

General

Brand	MST
Model	Impact NS5001
Category	Switch
Language	English
