Illustration
Procedur
e
Step
Release
the
catch
on
the
composite
bre/power
cable
port
and
remove
the
cover
.
1
Align
the
pins
on
the
connector
to
the
composite
port.
2
Insert
the
cable
into
the
composite
port,
and
push
the
locking
catch
to
the
connector
.
3
Remove
the
protective
cover
from
the
F-LINK
cable
port.
4
NS50
User
Guide
37
Revision
C
Installation
36
38
