Model Series 390
REF.
NO.
PART NO. DESCRIPTION
1. 712-0442 Acorn Lock Nut 1/4-20
2. 736-3020 Flat Washer.271” I.D. x.630” O.D.
3. 720-0270A Reverse Handle Grip
4. 731-1600 Handle Cover w/o throttle
5. 710-0779A Truss Mach. Scr. #10 x 1/2” Lg.
6. 720-0274 Handle Grip
7. 712-0287 Hex Nut 1/4-20 Gr.2
8. 726-0135 Cap Speed Nut
9. 686-0083 Clutch Handle Assembly
10. 720-0269 Clutch Grip
11. 710-0641 Hex Bolt 1/4-20 x 2.25” Lg. Gr.5
12. 731-1645A Clutch Handle Holder
13. 736-0140 Flat Washer.385” I.D. x.62” O.D.
14. 686-0014A Reverse Handle Ass’y
15. 736-0264 Flat Washer.344” I.D. x.62” O.D.
16. 649-0022B Handle Assembly Comp.
19. 749-1401 Handle Brace † or †††
20. 736-0921 Lock Washer 1/2 † or †††
21. 710-3194 Hex Bolt 1/2-20 Gr. 5 † or †††
22. 786-0005 Depth Bar
23. 714-0149B Cotter Pin
24. 712-3004A Hex Flange L-Nut 5/16-18 Thd. Gr.5
25. 786-0003 Tail Piece Bracket (L.H.)
26. 786-0004 Tail Piece Bracket (R.H.)
27. 711-0415 Clevis Pin
28. 710-0805 Hex Bolt 5/16-18 x 1.5” Lg.
29. 710-0189 Hex Bolt 5/16-18 x 3” Lg.
30. 736-0242 Wash. Bell.340” I.D. x.872” O.D.
31. 711-1036A Spec. Hex Nut
32. 736-0119 L-Wash. 5/16” I.D.
33. 710-3008 Hex Bolt 5/16-18 Gr. 5
34. 786-0129 Cable Guide Bracket
35. 710-0604A Hex Washer Screw 5/16-18 x.62” Lg.
36. 710-0602 Hex Wash. Hd. TT-Tap Scr.
37. 738-0934 Shdl. Bolt 5/16-18
38. 786-0138A Frame (R.H.)
39. 786-0139A Frame (L.H.)
40. 736-0171 Lock Washer 7/16
41. 712-0240 Jam Nut 7/16-20 Gr. 2
42. 710-0176 Hex Bolt 5/16-18 x 2.75” Lg.
43. 712-0429 Hex Nylon Nut 5/16-18 Thd.
46. 686-0081A Wheel Hanger Bracket Assembly
47. 734-1781 Wheel Ass’y 8” x 1.75”(Plastic)
734-1566 Wheel Ass’y 8” x 1.75” (Steel)
48. 738-0929 Shoulder Screw.496 I.D. x 1.445 O.D.
49. 750-0890 Spacer
50. 710-1236 Carr. Bolt 5/16-18 x 1
51. 749-0915A Engine Tube Brace (Std. B&S)
749-1082 Engine Tube Brace (Tec.)
52. 712-3004A Hex Flange L-Nut 5/16-18 Thd. ††
53. 786-0159 Engine Brkt. (Std. B&S)
54. 736-0242 Bell. Wash.34” I.D.
55. 720-0195 Hand Knob
56. 750-0470 Spacer
REF.
NO.
PART NO. DESCRIPTION
† Briggs & Stratton Intek Engine
†† Standard Briggs & Stratton and Tec. Engine
††† Honda Engine
