Technical Data
Channels: Two isolated independent channels
Waveform: Asymmetrical, rectangular, biphasic with zero DC-current
Intensity: 0 - 90 mA into 500 ohm load,
70 mA maximum into 1000 ohm load
65 mA maximum into 1500 ohm load
(Indication only, actual intensity varies depending on condition of the electrodes)
Classication: Internally powered, constant current, continuous operation, type BF applied part,
class IIa (MDD 93/42/EEC), IP 20
Frequency: 1 - 200 Hz
Pulse Width: 50 µs - 450 µs
Ramp up/down: 0,1 - 9,9 seconds
Time adjustment: 1 minute - 9 hours, 59 minutes
Power supply: 4 batteries 1,5 V type AA
Voltage max.:180 V without load (80 V into 1000 ohm load)
Dimensions: L 141,6 mm x W 74 mm x H 40,4 mm
Weight: 250 g (incl. batteries)
Environmental conditions for storage & transportation: 0-93% atmospheric humidity, -25 to
+70 degree centigrade. Environmental conditions for use: 0-93% atmospheric humidity, +5 to
+40 degree centigrade, air pressure 700-1060 hPa.
This device is quality controlled and fullls the rules and regulations set by the German law for
medical products (MPG) as well as the guidelines of the European Community 93/42/EEC for
medical products. Therefore this device carries the CE-sign „CE 0123“. The serial number is in
the battery compartment.
Manufacturer: MTR+ Vertriebs GmbH,
Kamenzer Damm 78, 12249 Berlin - www.mtrplus.com
Explanation of Symbols
