SineBravo Operators Manual
5
1. Dual Channel
2. EMG Range: 0.2 to 2000 µV RMS (continuous)
3. Sensitivity: 0.l µV RMS
4. Selectable Bandpass lter - 3db Bandwidth,
a. Wide: 18 Hz +/- 4 Hz bis 370 Hz +/- 10 % - Reading below 235 microvolts
10 Hz +/- 3 Hz bis 370 Hz +/- 10 % - Reading above 235 microvolts
b. Narrow: 100 Hz +/- 5 Hz bis 370 Hz +/- 10 %
5. Notch lter: 50 Hz - 33 dbs
6. Common Mode Rejection Ratio: 130 dbs Minimum @ 50 Hz
7. Batteries: 4 x AA
8. Work / Rest periods: 2-99 seconds
9. Number of Trials: 2-99
10. Dimensions: L 141,6 mm / W 74 mm / H 40,4 mm
11. Weight of the device: 270 g (incl. batteries)
12. Firmware version 3.1B or later
Max. environmental conditions for transportation: -25 to +70 degree centigrade, 0-93%
atmospheric humidity. Recommended environmental conditions for storage: -25 to +40 degree
centigrade, 0-93% atmospheric humidity. The device shall not to be stored in direct sunlight.
Allow up to one hour for the device to return to normal operating temperature if stored in
conditions below +5°C or above +40°C.
Environmental conditions for use: +5 to +40 degree centigrade, 0-93% atmospheric humidity,
air pressure 700-1060 hPa. During use the surface temperature of the device can be 41°C or
higher, but never exceeds 48°C.
The SineBravo is protected against debris larger than 12.5 mm in diameter from entering the
cabinet and is not water resistant and rated IP20.
Radio Link:
RF Frequency Range: 2.4000 GHz to 2.4835 GHz
RF Default Output Power: <= 1,0 mW
RF Maximum Output Power: <= 2,52 mW
Antenna Gain: 0 dBi
This device is quality controlled and fullls all legal requirements for medical products.
Therefore this device carries the CE-sign „CE 0123“. The serial number is on the rear of the
unit.
Manufacturer: MTR+ Vertriebs GmbH,
Kamenzer Damm 78, 12249 Berlin - Germany
www.mtrplus.com
Technical Data
