MTS Systems Level Plus User Manual

Appendix F LPM Modbus Register Maps
Map 1: Registers arranged by tank number
Modbus Register Data Address Data Description
30001 0000 Tank 1, Level 1 High Word (x 1000) see notes 2, 3, 4
30002 0001 Tank 1, Level 1 Low Word (x 1000)
30003 0002 Tank 1, Level 2 High Word (x 1000) see note 5
30004 0003 Tank 1, Level 2 Low Word (x 1000)
30005 0004 Tank 1, Average Temperature (x 100) see note 6
30006 0005 Tank 1, RTD1 (x 100) see note 1
30007 0006 Tank 1, RTD 2 (x 100)
30008 0007 Tank 1, RTD 3 (x 100)
30009 0008 Tank 1, RTD 4 (x 100)
30010 0009 Tank 1, RTD 5 (x 100)
30011 0010 Tank 1, Alarm Status, see note 8
30012 0011 Reserved, see note 9
30013 0012 Tank 1, GOVP High Word, see note 10
30014 0013 Tank 1, GOVP Low Word
30015 0014 Tank 1, GOVI High Word, see note 11
30016 0015 Tank 1, GOVI Low Word
30017 0016 Tank 1, GOVT High Word, see note 12
30018 0017 Tank 1, GOVT Low Word
30019 0018 Tank 1, GOVU High Word
30020 0019 Tank 1, GOVU Low Word
30021 0020 Tank 1, NSVP High Word
30022 0021 Tank 1, NSVP Low Word
30023 0022 Tank 1, Mass High Word
30024 0023 Tank 1, Mass Low Word
30025 0024 Reserved
30026 0025 Reserved
30051 0050 Tank 2, Level 1 High Word (x 1000)
30052 0051 Tank 2, Level 1 Low Word (x 1000)
30053 0052 Tank 2, Level 2 High Word (x 1000)
30054 0053 Tank 2, Level 2 Low Word (x 1000)
30055 0054 Tank 2, Average Temperature (x 100)
30056 0055 Tank 2, RTD 1 (x 100)
30057 0056 Tank 2, RTD 2 (x 100)
30058 0057 Tank 2, RTD 3 (x 100)
30059 0058 Tank 2, RTD 4 (x 100)
30060 0059 Tank 2, RTD 5 (x 100)
30061 0060 Tank 2, Alarm Status
30062 0061 Reserved
30063 0062 Tank 2, GOVP High Word
