Net product volume and net product mass information (mode #2) can be displayed by depressing
the FNCTN key and then depressing the numeric “2” key (within 3 seconds). See example.
Mode #2 Volume Display
Tank capacity (volume) information is accessed by volume display mode #3. Working capacity,
safe fill, and maximum safe fill information can be displayed by depressing the FNCTN key and
then the numeric “3” key. See example.
Mode #3 Volume Display
Gross total volume and net product volume information (Mode #4) can be displayed by depress-
ing the FNCTN key and the numeric “4” key. See example.
Mode #4 Volume Display
If the Level Plus is programmed for volume mode, basic level/temperature information can be
displayed using mode #5.
Mode #5 Level Display
Individual RTD data can be displayed by depressing the FNCTN key and the numeric “6” key. See
example. This screen includes product level, average temperature, individual RTD temperatures
and alarm information. The RTD data is displayed on lines two and three with RTD #1, 2 and 3
on line two and RTD #4 and 5 on line three. If an RTD is not programmed (or disabled) the dis-
play will show *NA (not active).
Mode #6 RTD Display Mode
#1 112.99 in 80.5 °F
80.4 :80.3 :80.7
80.6 :*NA
PRDHH INTLO TMPHI
TANK#1: 96.667 in.
INTER: 2.667 in.
TEMP: 72.0 °F
PRDHH INTLO TMPHI
#1 112.99 in 80.5 °F
GOVT 9999999 GAL
NSVP 9999999 GAL
PRDHH INTLO TMPHI
#1 WC 10000 GAL
SF 11000 GAL
MSF 12000 GAL
PRDHH INTLO TMPHI
#1 112.99 in 80.5 °F
NSVP 9999999 GAL
MASS 9999999 LBS
PRDHH TMPHI
20
