Temposonics
®
R-Series V Analog
Operation Manual
I 35 I
8.2 Technical data Temposonics
®
RH5
Output
Analog Voltage: 0…10 /10…0/−10…+10/+10…−10 VDC (min. controller load > 5 kΩ)
Current: 4(0)…20/20…4(0) mA (min./max. load 0/500 Ω)
Measured output variables Position for one or two position magnets
Position + speed (without direction) or velocity (with direction) for one position magnet
Position for one position magnet + temperature inside the sensor electronics housing
Measurement parameters
Position measurement
Null/Span adjustment 100 % of electrical stroke
Resolution 16 bit (internal resolution 0.1 µm)
Linearity deviation
5
< ±0.01 % F.S. (minimum ±50 µm)
Repeatability < ±0.001 % F.S. (minimum ±1 µm)
Hysteresis < 4 µm
Update time
Stroke length ≤ 1200 mm ≤ 2400 mm ≤ 4800 mm ≤ 7620 mm
Update time 0.5 ms 1.0 ms 2.0 ms 5.0 ms
Velocity measurement
Range 0.01…10 m/s or 1…400 in./s
Deviation ≤ 0.05 %
Resolution 16 bit (minimum 0.01 mm/s)
Operating conditions
Operating temperature −40…+85 °C (−40…+185 °F)
Humidity 90 % relative humidity, no condensation
Temperature coef cient < 30 ppm/K
Ingress protection IP67 (connectors correctly tted)/IP68 for cable outlet
Shock test 150 g/11 ms, IEC standard 60068-2-27
Vibration test 30 g/10…2000 Hz, IEC standard 60068-2-6 (excluding resonant frequencies)/
RH5-J: 15 g / 10…2000 Hz, IEC standard 60068-2-6 (excluding resonant frequencies)
EMC test Electromagnetic emission according to EN 61000-6-3
Electromagnetic immunity according to EN 61000-6-2
The sensor meets the requirements of the EC directives and is marked with
Operating pressure 350 bar (5,070 psi)/700 bar (10,150 psi) peak (at 10 × 1 min) for sensor rod/RH5-J: 800 bar (11,600 psi)
Magnet movement velocity Any
Design / Material
Sensor electronics housing Aluminum (painted), zinc die cast
Sensor fl ange Stainless steel 1.4305 (AISI 303)/RH5-J: Stainless steel 1.4305 (AISI 303)
Sensor rod Stainless steel 1.4306 (AISI 304L)/RH5-J: Stainless steel 1.4301 (AISI 304)
Stroke length 25…7620 mm (1…300 in.)/RH5-J: 25…5900 mm (1…232 in.)
Mechanical mounting
Mounting position Any
Mounting instruction
Please consult the technical drawings on page 12
Electrical connection
Connection type 1 × M16 male connectors (6 pin) or cable outlet
Operating voltage 12…30 VDC ±20 % (9.6…36 VDC)
Power consumption < 3.25 W
Dielectric strength 500 VDC (DC ground to machine ground)
Polarity protection Up to −36 VDC
Overvoltage protection Up to 36 VDC
5/ With position magnet # 251 416-2
