mtts Dolphin CPAP - CPAP Setup - PEEP Chamber Preparation; Assemble and Fill PEEP Chamber

V.1.04.EN
Dolphin CPAP. User manual
22
Setup (CPAP)
2. Assemble and ll the PEEP Chamber.
The numbers on the column indicate the depth of the column (in cm) in the

23
Setup (CPAP)
Fill the bottle with distilled or sterile
water until the water level reaches the

A.
Attach the screw cap by twisting it until
tight.
B.
Insert the spring into the screw cap in
the orientation shown in the picture.
C.
Line up the notch in the column with the
plastic extension of the spring. Press in
the spring and begin to insert the
column into the bottle. When the
numbers on the column reach the cap,
you will need to twist the column back-
and-forth to continue inserting it. Once
you have reached the desired depth,
release the spring to lock the column
in place.
D.
Place the assembled PEEP Chamber in
the PEEP Chamber holder.
E.
