Delivered pressure
The PEEP column can be set at integer values in the range of 1 - 10 cmH
2
O.
rate. The relationship between pressure delivered at the patient interface connection site, PEEP column setting, and
Specications
Specications
Control Settings
Set FiO
2
Airway temperature probe (T2)
Displays
Measured temperature display
Measured FiO
2
display
Humidier
Warm-up time
Humidity performance
Volume available for vaporization
Maximum operating pressure
Heater plate overtemperature cutout
6 L/min
4 - 9 L/min
2
2
2
2
20 mL
1600 mL (maximum)
7 kPa
Default
Range
Default
Range
Default
Range
Default
Range
Accuracy
Range
Accuracy
Range
Humidity chamber
Reservoir
The pressure delivered to the patient is lower than the pressure delivered to the patient interface connection
site. This is because there is a pressure loss across the patient interface. Different patient interfaces have
different amounts of pressure loss.
These values may not be accurate if you do not use the recommended breathing circuit components, or if the
Pressure Delivered at the Patient Interface Connection Site [cmH
2
O]
Flow Rate Setting [L/min]
4 5 6 7 8 9
PEEP column setting [cmH
2
O]
1 1.8 1.9 2.0 2.2 2.4 2.6
2 2.8 2.9 3.0 3.2 3.4 3.6
3 3.9 4.0 4.1 4.3 4.5 4.7
4 4.9 5.0 5.1 5.3 5.5 5.7
5 6.0 6.1 6.2 6.4 6.6 6.8
6 6.9 7.0 7.1 7.3 7.5 7.7
7 8.0 8.1 8.2 8.3 8.5 8.7
8 8.9 9.0 9.1 9.2 9.4 9.6
9 9.8 9.9 10.0 10.1 10.3 10.5
10 10.8 10.9 11.0 11.2 11.3 11.4
