Device Description
Device Description
14
15
Humidier
Plastic Body
Metal Plug O-ring
(non removable)
Metal Plug
Screw Cap
Screw Cap O-ring
(non removable)
Breathing Circuit
Straight connector
with airways tempera-
ture probe (T2)
Heater wire
assembly with straight

temperature probe (T1)
Plastic Body
Screw Cap
Metal Plug
Temperature sensor
cable
Inspiratory Tube
(heated)
Silicone connector
Wye connector
Expiratory Tubes
(not heated) 45 and 60
cm
Heater wire
power cable
(yellow)
Water Trap
