Engine, right side
Item Designation Monitoring of
1 F41 2-2-directional control valve
2 YB33 Fuel temperature
3 B48 Fuel pressure (in rail)
4 B16 (optional) Coolant pressure
5 F46 Leak fuel level
6 Y27.2 4-2-directional control valve, B-side
7 B4.22 Exhaust temperature, B-side
M015650/06E 2018-05 | General Information | 31
TIM-ID: 0000008412 - 005
